Need a tailored protocol? Add our Adapter Box to bridge your preferred interface without changing your core system. It translates seamlessly and keeps your integration clean and compliant.
DC Grid Meter
metering - measuring - monitoring
The DC Grid industry is experiencing significant growth, driven by increasing adoption of renewable energy sources, improvements in energy efficiency, and the need for reliable decentralized power solutions.
3D Hall
Based on our in-house developed 3D-Hall ASIC (AST proprietary), our DC Meter enables a continuously highly precise and bidirectional measurement of transferred energy.
This impressive performance makes the DC energy meter particularly suitable for industrial applications, mobility solutions, and use in hybrid AC/DC microgrid systems.
Certification and Compliance
Our DC energy meters are certified according to:
German Calibration Law: Module B (Production site according to Module D)
MID 2014/32/EU: EN 50470-4, IEC 62052-31
UL 61010
French Calibration Law: Décision n° 22.00.570.001.1 dated March 1, 2022
Our DC Meters comply with the accuracy requirements of Class B (MID 2014/32/EU) and Accuracy Class 1 of IEC62053-41:2021.
THE AST M³ SYSTEM TECHNOLOGY
MONITORING (Reporting)
- Visualization of data
- Focus on historical periods
- Reporting and transparency
MEASURING (Control)
- Highly accurate, real-time measurement
- Control & Process Optimization
METERING (Billing)
- Legally compliant metering
- Required for financial transactions
Design
With a unified interface standard and an installation footprint optimized for your system design, the device integrates seamlessly into your application. Thanks to its streamlined architecture, extensive and complex integration efforts are no longer required. This ensures faster commissioning, reduced engineering time, and a more efficient overall setup.
DC Meter
- Product family that covers the full measurement range
- Current: 2A - 5.000A
- Voltage: up to 1.500V
- For low current applications
- Current: 1A - 160A
- Voltage: up to 1.000V
Adapter Box
DC Measurement Smart Grid
For the planning and control of smart grids in the future, measurements of much higher currents and voltages are required. The variants DC3000 and DC5000 will contribute to optimizing efficiency and sustainability in energy distribution through extremely precise measurements and secure power monitoring.
DC160
The DC160 is a powerful measuring device specifically designed for precise direct current measurements in the lower power range. With its combination of high accuracy, reliability, and ease of use, the DC160 is tailored to meet the requirements of DC grids.
* sample quanities available
DC3000
In addition to its use in MCS, our current research and development efforts focus on the requirements of Smart Grids. With high accuracy and performance, we aim to enable precise measurements in large power grids as well as wind and solar parks. This contributes to intelligently controlling energy consumption.
* sample quantities available
DC5000
Our research in the field of smart grid measurement goes far beyond conventional solutions. Through continuous innovation and the commitment of our team, we are developing DC meter solutions that meet the requirements of the power grids of tomorrow.
* sample quanities available
Transparent Billing:
- Traceable, auditable DC billing according to MID andGerman Eichrecht
- End-to-end transparency from source to Smart-Meter-Gateway
- Tamper-proof, cryptographically secured data
Technical Features:
- High sampling accuracy and real-time data acquisition for bidirectional energy flow
- Modular communication design supporting Modbus RTU, Modbus TCP, Ethernet and PROFINET
More Information?
You can find these in our free product brochure.
With the DC Grid Meter, AST delivers maximum safety and precision. Building on our company’s history, we bring many years of experience in the mobility and sensor industries and transform this expertise into innovative DC grid solutions.
Let’s shape the DC grids of the future together!
